Leading Ceramic PCB Precision Manufacturing
Ceramic PCB Manufacturing Advantage
Thermal Management Expert
Superior thermal conductivity for efficient heat dissipation in high-power applications.
In-house Assurance
Complete in-house manufacturing for quality control and consistent performance.
Fast-turn Delivery
Quick turnaround for prototype and production orders with standard lead times.
Advanced Ceramic PCB Production Excellence
Precision Cutting
High-precision cutting for complex shapes and tight tolerances.
Laser Drilling
Laser drilling for microvias in ceramic substrates with high accuracy.
Vacuum Coating
Advanced vacuum metallization for uniform conductive layers.
Pattern Plating
Precision pattern plating for circuit formation with controlled thickness.
Ceramic PCB Manufacturing Capability
| Specification | Our Capability |
| Material Types | AlN (Aluminum Nitride), Al2O3 (Alumina), Si3N4 |
| Thermal Conductivity | 24 – 230 W/mK |
| Layers | 1-8 layers |
| Min Line Width/Spacing | 0.1mm / 0.1mm |
| Min Hole Size | 0.3mm |
| Max Operating Temp | Up to 1000C |
| Surface Finish | ENIG, Immersion Silver, HASL |
Quality Control of Ceramic PCB
Quality Control Equipment
- TDR (Time Domain Reflectometer)
- VNA (Vector Network Analyzer)
- AOI (Automated Optical Inspection)
- X-ray Inspection
Quality Standard Certificates
- ISO 9001:2015
- ISO 14001:2015
- IPC Class 2/3
- Material Certificates
Ceramic PCB Application
- LED lighting systems
- Automotive power electronics
- High-frequency communication
- Power modules and inverters
- Medical devices
- Aerospace applications
Ceramic PCB FAQ
What are the advantages of ceramic PCBs?
Ceramic PCBs offer superior thermal conductivity (24-230 W/mK), excellent electrical insulation, and high temperature resistance compared to traditional FR4 materials.
