Metal Core PCB Manufacturing – MCPCB LED Aluminum PCB Supplier
Metal Core PCB Manufacturing Advantage
In-house Integration
Complete in-house manufacturing for MCPCB production, from dielectric lamination to final testing, ensuring quality control at every stage.
Advanced Equipment
Specialized thermal lamination and dielectric coating equipment for precise thermal conductivity control in metal core PCB manufacturing.
High-Mix, Low-Volume
Extensive experience handling high-mix, low-volume MCPCB orders with quick turnaround for prototype and pre-production runs.
Advanced Metal Core PCB Production Excellence
Thermal Lamination
Precision thermal lamination process for reliable bonding between dielectric layer and metal substrate, ensuring consistent thermal performance.
LED Thermal Design
Engineering support for LED thermal management design, including thermal simulation and DFM analysis to meet junction temperature targets.
Multiple dielectric Options
Various dielectric material options from standard (1.0 W/mK) to high thermal (3.0 W/mK) conductivity to optimize cost-thermal performance.
Quality Assurance
Rigorous testing including thermal cycling, thermal shock, and LED lifecycle testing to ensure reliability in demanding applications.
Metal Core PCB Manufacturing Capability
| Specification | Our Capability |
| Core Material | Aluminum 5052, 6061, 6063; Copper |
| Thermal Conductivity | 1.0 – 3.0 W/mK (dielectric) |
| Min Dielectric Thickness | 0.05mm (2mil) |
| Circuit Layers | 1-4 layers (single/double sided) |
| Copper Weight | 1oz – 6oz |
| Min Line Width/Spacing | 0.15mm / 0.15mm |
| Max Board Size | 1000mm x 600mm |
| Surface Finish | HASL, ENIG, Immersion Silver, OSP |
Quality Control of Metal Core PCB
Quality Control Equipment
- Automated Optical Inspection (AOI)
- Thermal Cycling Test
- Thermal Shock Test
- LED Lifecycle Testing
Quality Standard Certificates
- ISO 9001:2015
- ISO 14001:2015
- IPC Class 2/3
- UL Certification
Metal Core PCB Application
- LED Lighting: Commercial downlights, street lamps, high-bay lights, LED modules, horticulture lighting
- Power Electronics: DC-DC converters, LED drivers, SMPS modules
- Automotive: Headlights, taillights, interior lighting, EV battery cooling
- Solar & Renewable: Solar inverters, microinverters, charge controllers
- Audio Equipment: High-power amplifiers, subwoofer boards
Metal Core PCB FAQ
What is the difference between aluminum MCPCB and copper core PCB?
Aluminum MCPCB is the most common and cost-effective option with thermal conductivity around 150 W/mK. Copper core PCB offers superior thermal conductivity (400 W/mK) and is used for high-power applications where maximum heat dissipation is critical.
What thermal conductivity do I need for LED applications?
For general LED lighting applications, 1.0-1.5 W/mK dielectric is sufficient. For high-power LEDs or designs requiring operation in elevated ambient temperatures, 2.0-3.0 W/mK dielectric is recommended.
Metal Core PCB Solutions
Read our technical articles about metal core PCB thermal design and manufacturing best practices for LED and power electronics applications.
